630A-1250A /11kv Indoor Solid Fully Insulated Enclosedring Net Switchgear

Ask Latest Price
Video Channel
Brand Name :QIUPU
Model Number :EGC/XGN15-12/V/630A-1250A
Certification :IEC
Place of Origin :wenzhou
MOQ :Negotiable
Price :Negotiable
Payment Terms :L/C, D/A, T/T, Western Union
Supply Ability :5000
Delivery Time :7 days
Packaging Details :wooden
Product Name :Fixed Switchgear
Rate voltage :11kV
Rate frequency :50Hz
Rated main bus bar current :630A ,1250A
Short-time withstand current(4S) :20,25,31.5,40 KV
Peak withstand current(peak.) :50,63,80,100 KV
Rated short drop out current :20,KV
Rated short circuit open and cut(Peak) :50,KV
more
Contact Now

Add to Cart

Find Similar Videos
36kV Air Insulated Metal Clad Withdrawable Switchgear 00:31
36kV Air Insulated Metal Clad Withdrawable Switchgear
High Voltage Gas Filled Switchgear CVCC 12kV Electrical SS304 00:29
High Voltage Gas Filled Switchgear CVCC 12kV Electrical SS304
Five Anti Interlock KYN28-12 TypeType MV Fixed Switchgear 00:25
Five Anti Interlock KYN28-12 TypeType MV Fixed Switchgear
Metal Clad MV Medium Voltage Switchgear SF6 630A 12kV 00:31
Metal Clad MV Medium Voltage Switchgear SF6 630A 12kV
3 Phase AC 50Hz 12kV Metal Clad Withdrawable Switchgear 00:22
3 Phase AC 50Hz 12kV Metal Clad Withdrawable Switchgear
EGC/GT-12/C 630 Indoor 12kV High Voltage Solid State Switchgear 1.5 M 00:26
EGC/GT-12/C 630 Indoor 12kV High Voltage Solid State Switchgear 1.5 M
Enclosed Anti Interlock 50Hz 24kV Medium Voltage Fixed Switchgear 00:29
Enclosed Anti Interlock 50Hz 24kV Medium Voltage Fixed Switchgear
12kV HXGN-12 Metal Clad MV Medium Voltage Switchgear SF6 630A 00:32
12kV HXGN-12 Metal Clad MV Medium Voltage Switchgear SF6 630A
Indoor Solid Insulation Switchgear GTXN-12/630A-25kA 50Hz DC110V/220V/48V 00:42
Indoor Solid Insulation Switchgear GTXN-12/630A-25kA 50Hz DC110V/220V/48V
IP43 Prefab Electric Compact Substation Transformer 15kv 00:22
IP43 Prefab Electric Compact Substation Transformer 15kv
View Product Description

630A-1250A /11kv Indoor Solid Fully Insulated Enclosedring Net Switchgear

Description:
11kV switchgear is the latest generation of indoor complete power distribution equipment with three phase AC 50Hz or 60Hz, 3.6kV to 12kV single busbar section system. It's mainly used in power plant, substation, industrial and mining factories, as well as high-rise buildings, for power reception and power distribution, with functions of controlling, protecting and detecting electric circuits.
Features:

1. Metal-clad and fully enclosed structure, can prevent dirt and small animals from entrance.

2. Each small compartment in the switchgear is separated and independent from each other.

3. Fast closing earthing switch is used for earthing and provides short-circuit current closing capacity.

Technical parameters:

Items Unit parameter
Rate voltage kV 11
Rate frequency Hz 50
Rated main bus bar current A 630 ,1250,1600,2000,2500 ,3150
Rated branching bus bar current A 630 ,1250,1600,2000,2500 ,3150
Short-time withstand current(4S) kV 20,25,31.5,40
Peak withstand current(peak.) kV 50,63,80,100
Rated short drop out current kV 20,25,31.5,40
Rated short circuit open and cut(Peak) kV 50,63,80,100
Rated insulation level 1min power frequency
withstand voltage
ph-ph,ph-ground kV 25,30,42
breaker gap kV 27,34,48
Rated lighting impulse withstand voltage(Peak) ph-ph,ph-ground kV 40,60,75
breaker gap kV

46,70,85

630A-1250A /11kv Indoor Solid Fully Insulated Enclosedring Net Switchgear630A-1250A /11kv Indoor Solid Fully Insulated Enclosedring Net Switchgear630A-1250A /11kv Indoor Solid Fully Insulated Enclosedring Net Switchgear

Switchgear Structure:

1. Switchgear is composed of cubicle and removable parts (so called trolley). The cubicle is separated into several functional compartments by metal sheet, including busbar compartment, circuit breaker compartment, cable compartment and low voltage

2. Switchgear removable parts can be equipped with VCB trolley, voltage transformer trolley, lightning arrester trolley and fuse trolley.

3. Pressure relief devices are installed above trolley compartment, busbar compartment and cable compartment. Special sealing ring on the door seals the panel door.

4. In case of faults inside the compartments resulting in arc, the pressure is going up inside the switchgear and the pressure relief equipped on the top will open automatically, to release pressure and high temperature gas. In this way, it can ensure the safety of operating staff and the switchgear.

630A-1250A /11kv Indoor Solid Fully Insulated Enclosedring Net Switchgear

About Us

Wenzhou Qiupu Electric Power Co., Ltd. is located in Yueqing Economic Development Zone, Zhejiang Province. It is a high-tech enterprise specializing in the research and development, production and sales of electric power products such as circuit breakers, transformers, power distribution switches and high and low voltage electrics.

Our products are widely used in financial, communications, municipal, transportation, power, construction, aerospace, industrial control and other important areas, has won the majority of users praise and signed a long-term cooperation agreement.

FAQ

Q1: Is OEM/ODM available?
A1: Yes, it is! Our products can be Customized. We have design and engineer teams,we can customize products according to customers' drawing or requirements.

Q2: What's your MOQ?
A2: One Set.

Q3: How is the delivery time?
A3: It depends your order quantity and it normally takes about 20-30 days.

Q4: How do you control the quality?
A4: We have QC team comply with TQM to ensure the quality. Each step is in compliance to the standards. At the same time, we will take photos and shoot video for you if you need.Every product will be fully assembled and carefully tested before packing and shipping.

Q5: How long is the warranty?
A5: Within one year from the sale date, if there are any accessory problems, you just provide the photos of damaged accessory, then we will provide free accessory. According to the number of products, we will provide easily damaged accessories for free. We also can provide technical support if you need.
